Hyundai DHY14KSE Silenced 3-Phase Diesel Generator 11kW/14kVA

Hyundai DHY14KSE Silenced 3-Phase Diesel Generator 11kW/14kVA

The Hyundai DHY14KSE is a three phase diesel generator with a maximum output of 11kW. Designed for domestic or professional use, the DHY14KSE is powered by a 14hp diesel engine and is equipped an AVR alternator to produce clean energy. This means that any sensitive electronic equipment, such as televisions, PCs and laptops, can safely be powered by the DHY14KSE.

The DHY14KSE can be started manually by using the key, or connected to an ATS (Automatic Transfer Switch) system. An ATS system will automatically detect a loss of power from the mains, turn your DHY14KSE on automatically, and then turn it off again when power returns from the mains.

Housed in a weather-proof “silenced” canopy, the DHY14KSE produces only 65dB @ 7 metres which makes it a quiet standby generator which won’t interrupt you at home or work.

All Hyundai 1500rpm diesel generator sound proof canopies undergo an anti-corrosion painting process called electrophoretic painting. This process ensures all areas of the canopy have an evenly applied thickness of paint, ensuring maximum corrosion protection.

The DHY14KSE benefits from being an economical diesel generator, capable of running on red diesel which is significantly cheaper than road diesel and is safer to store than petrol.

Running at 1500rpm, the engine is stressed less than in 3000rpm generators and this helps extend the lifespan of the machine if properly serviced.

Specifications:

• Rated Power (kW/kVA): 10/13
• Max Power (kW/kVA): 11/14
• Frequency: 50
• Voltage(s): 230, 400
• Controller: IL-NT MRS 10
• ATS Port Included
• Fuel Capacity: 46l
• Cooling Fluid Volume (L): 10
• Fuel Consumption (l/h): 2.2 / 4.2
• Engine Model: HY480
• Power Output (hp): 14
• Rotate Speed (rpm): 1500
• Mechanical Speed Regulation
• Displacement: 1809cc
• Oil Capacity (L): 10
• Alternator: AVR
• Power Factor (Cos?): 0.8
• Low Oil Pressure: Yes
• Block On Start-up: Yes
• Low Battery: Yes
• High Temperature On Water: Yes
• Low Oil Level: Yes
• Low Running On Engine: Yes
• Emergency Stop: Yes
• Noise @ 1m: 92
• Noise @ 7m: 65
• Weight: 710kg
• 2 Years manufactures warranty
